LIGHT DUTY 3 INCH Poly/Poly CASTERS
Part Numbers
Series-Wheel Diameter/Wheel Width/Bearing/Wheel Material-Brake Options-Mounting Options
LDS-317PP
Caster Specifications
250 lb capacity / 95 Shore A
Ball Bearing Standard (other bearing options available)
Temperature range: -45 F through 180 F
Wheels are non-marring and non-marring
Resistant to most solvents, oil and grease
Brake Options
Top Lock (Vert Lock) Brake (-TLB)
Side (Cam) Lock Brake (-SB)
Total Lock Brake (-TTL)
Top Plate Mounting Options
Top Plate Options:
2-3/8" x 3-5/8" (standard)
3-1/8" x 4-1/8" (-TP3)
3-1/2" x 3-1/2" (-TP4)
4 x 4-1/2" (-TP5)
Threaded Stem Mounting Options
Threaded Stem Options:
1/2"-13 x 1-1/2" (-TS1)
1/2"-13 x 1" (-TS2)
Other stem sizes available
Expander Stem Mounting Options
Rubber Expanding Stem Options:
Measured by Tube Inside Diameter
7/8" (-11APP)
1-1/8" (-15APP)
1-3/16" (-17APP)
1-3/8" (-19CAPP)
1-1/2" (-19APP)
1-3/4" (-21APP)
Grip (Friction) Ring Mounting Options
Grip Ring Options:
7/16" x 1-3/8" (-GR1)
7/16" x 7/8" (-GR2)
7/16" x 2" (-GR3)
5/8" x 2-3/16" (-GR4)
7/8" x 2" (-GR5)
Other Mounting Options Available
If you don't see your specific caster type listed here, let us know. When in doubt, send us a picture of your caster, and we can match it up.
